The animal feed production line is mechanical equipment that specializes in making animal feed. For example, it can produce chicken feed, cattle feed, sheep feed, pig feed, horse feed, cat food, dog food, fish feed, shrimp feed, and so on.
The complete cattle feed pellet production line uses barley, forage, pulses, bran, wheat, corn, and additives such as vitamins, minerals, and other essential trace ingredients to produce feed pellets. The granules are rich in nutrients and can meet the growing needs of cattle at different growth stages. By combining the moisture, heat, and pressure of the feed ingredients, a degree of gelatinization is created, which allows cattle to better utilize the nutrients in these ingredients. Feed pellets are widely used in small farms, large farms, and medium-sized feed mills.
Our premium cattle feed pellet production line includes grain hammer mills, conveyors, mixers, cattle feed pellet mills, coolers, crushers, screeners, automatic packaging machines, and more. 2-12mm cylindrical feed pellets are available according to your needs.
At the same time, the cattle feed production plant has the characteristics of low energy consumption, high production efficiency, and large profits. It is especially suitable for large feed mills, breeding farms, large farms, etc. At the same time, we provide free installation, training, factory design, and timely after-sales service.
1. Who is Suitable for This Cattle Feed Mill Plant?
This cattle feed mill plant is specially designed for farmers, animal farm plants, animal feed suppliers, etc.
2. What Raw Material Can Use in The Cattle Feed Mill Plant?
Cattle feed mill plant raw materials include corn/maize, wheat, grass, alfalfa, oilseed meal & cakes, pasture, bone meal, microelements, etc., and other kinds of raw materials, such as premix, vitamins, wheat bran, salt and other. Different formulations can be made according to different formulas and the needs of the animals being farmed.
3. What Kind of Cattle Feed Pellet Production Line Can Produce?
This feed pellet production line can produce feed for meat cattle, broilers, laying hens, small baby cattle feed, cattle feed, pig feed, duck feed, sheep feed, poultry feed, livestock feed, goat feed, etc. Such as 2-4mm diameter chick feed pellets and pig feed pellets. 2-5mm rabbit feed pellets, 4-8mm cattle or sheep feed pellets.
This feed pellet mill with ring dies, makes pellets of 2-10mm in diameter, the pellet size can be changed with our feed pellet machine by adjusting the die.
4. Why Choose Our Cattle Feed Production Line?
Widely Applications: This cattle feed pellet mill plant can make feeds for cattle, broilers, hens, poultry, livestock, sheep, pig, cattle, ducks, and other animals, it makes pellets of 2-12mm diameter, and the pellet size is can be changed with our feed pellet machine by adjusting die.
Small Investment: the compact design of this feed mill plant can reduce the investment in workshops.
Low Installation Cost: our cattle feed production line comes with detailed installation and commissioning instructions, it is easy to install the machine, and you can use it immediately after the machine is installed.
Low Production Cost: The cattle feed factory only needs a few production workers to complete the production operation. With less labor and lower production costs, your profits will increase.
5. What Can We Do for You?
We can provide the project design, flow chart, feed-making machine manufacturer, project installation and commission, staff training, after-sales service, etc. Also, our professional install team will serve you if you need it.
Feed Pellets Processing Technology
Raw Material → Feed Grinding → Feed Mixing → Feed Pelletizing → Pellet Cooling → Pellet Crushing → Screening & Grading → Pellet Packing
Equipment Related to Complete Feed Manufacturing Plant
Feed Grinder →Feed Mixer → Feed Pellet Mill → Counterflow Cooler → Feed Pellets Crumbler → Feed Pellets Grading Sieve → Automatic Weighing and Packing Machine
Storage of The Raw Materials
There are many different raw materials and materials in the feed, so various types of silos must be used. There are three types of silo that can be used in the feed pellet line, such as hopper silo, flat bottom silo, and galvanized silo.
Cleaning of Raw Materials
Impurities in feed raw materials not only affect the quality of feed products but also directly affect the use of feed processing equipment and the personal safety of staff. In severe cases, the entire equipment will be damaged and the smooth progress of feed production will be affected. Therefore, impurities in the feed raw materials should be removed in time.
Crushing of Raw Materials
The technological process of feed crushing is determined according to the required particle size, feed variety, and other conditions. The number of raw material crushing can be divided into primary crushing process and circulating crushing process, or secondary crushing process. The combination with the batching process can be divided into the first batching and then crushing process and the first crushing and then batching process.
Batching Process
The rational design of the batching process is to correctly select the specifications and quantities of the batching metering device so that it is fully coordinated with the combination of batching feeding equipment, mixing units, and other equipment.
Mixing Process
The mixing process refers to the technological method and process of weighing the ingredients in the feed formula and then entering the mixer for uniform mixing. The mixing section requires a short mixing cycle, high mixing quality, fast discharge, low residual rate, good airtightness, and no dust spillage.
Pelleting Process
The pelleted feed obtained by compacting and extruding a single raw material or compound mixture by mechanical action is called feed pelleting. The purpose of pelleting is to use the heat, moisture, and pressure in the pelleting process to pelletize the feed that is finely divided, easily dusty, poorly palatable, and difficult to transport.
Cooling Process
During the pelleting process, when the pellet feed comes out of the feed pellet machine, the water content reaches 16%-18%, and the temperature is as high as 75°C-85°C. It will also cause adhesion and mildew during storage. The moisture must be reduced to below 14%, the temperature must be below 8°C higher than the air temperature, and cooling is required.
Crumbling Process
In the production process of the feed pellet mill, in order to save electricity, increase productivity and improve quality, the material is often made into a certain size of pellets and then crushed into qualified products according to the size of the feed pellets.
Screening Process
After the pellet feed is processed by the crushing process, some unqualified materials such as powder will be produced. Therefore, the crushed pellet feed needs to be sieved into a product with neat particles and uniform size.
Packaging Process
After weighing, put the finished product into the packing scale and pack it. During this process, the package should be calibrated until the package weight standard is met.
